铝单板幕墙 Pate curtain walls 铝单板厂家

 铝单板幕墙 Pate curtain walls 铝单板厂家

 Pate curtain walls adopt high-quality and high strength aluminum plate. its common height is 2.0mm,2.5mm,3.0mm,and its model is  1100,3003,and its state is H24.Besides its general material s maximum dimension is 1300mm*4000mm,and its structure is composed of front -panel,reinforced rib ,and angle ,front -pages is directly flexed,and then stamped to form an angle bracket, it also can be formed by riveting angel bracket on the panels flanging.reinforced rib is jointed with electric welding bolt behind structureplate in order to form a firm structure ,so, it strengthens aluminum curtain walls strength and rigidity,and ensures its flatness and ability so resist wind and shock during its long-term use. if need additional sound insulation and  heat preservation effects ,the special materials can be fixed inside the aluminum sheet.

   铝单板幕墙采用优质高强度铝合金板材，其常用厚度为2.0，2.5，3.0，型号为1100系列，3003系列，状态为H24.常规材料较大尺寸为1300mm*4000mm.其结构主要由面板，加强筋和角码组成。角码可直接由面板折弯，冲压成型，也可在面板的折边上铆装角码成型。加强筋与板面后的电焊螺钉连接，使之成为一个牢固的整体，极大增强了铝单板幕墙的强度与刚性，保证了长期使用中的平整度及抗震能力。如果需要隔音保温，可在铝板内侧安装高效的隔音保温材料。
